ADATA 8GB 1600 XPG DDR3 Memory Review Version 2.0 (AX3U1600GC4G9-DG2)

1. Introduction2. ADATA 8GB 1600 XPG DDR3 V23. Testing Methodology, Setup and Overclocking4. KitGuru Photoshop Benchmark5. AIDA 646. SiSoft Sandra7. 3D Studio Max 20118. Cinebench R11.5 64 bit9. MaxxMem 210. Closing Thoughts11. View All Pages

This version of the script has been thoroughly tested on Adobe Photoshop CS5 and CS4 and is compatible with Photoshop 7. It is important to document however that different versions of Photoshop give different end results. Adobe have been fine tuning the program over the years and enhancing specific filters and algorithms for better performance (some filters were rewritten during the CS2 time period). This means ultimately that comparing times with users running other versions of Photoshop is not going to give consistent results.

All results were gained from Adobe Photoshop CS5 64bit exe on Windows 7 64 bit ultimate and are marked in seconds. Lower times are better.

KitGuru PS Bench 1(4)	Standard 1333mhz 9-9-9-24	ADATA 1630 mhz 9-9-9-24	ADATA 1900mhz 9-11-9-27
1. Texturiser (1)	1.8	1.7	1.7
2. CMYK	1.9	1.9	1.9
3. RGB	1.8	1.8	1.8
4. Ink outlines	27.1	27.0	26.9
5. Dust & Stratches	2.9	2.7	2.7
6. Watercolor	25.6	25.4	25.2
7. Texturiser (2)	1.8	1.7	1.7
8. Stained Glass	18.9	18.8	18.5
9. Mosiac Tiles	12.3	12.1	12.0
10. Extrude	154.2	153.7	153.3
11. Rough Pastels	10.8	10.7	10.6
12. Smart Blur	88.2	88.2	88.0
13. Underpainting	31.4	31.3	31.1
14. Mosiac Tiles	11.8	11.7	11.4
15. Spherize	2.2	2.2	2.2
16. Palette Knife	18.7	18.6	18.4
17. Sponge	36.5	36.4	36.2
18. Smudge Stick	11.3	11.3	11.2
Total:	459.2	457.2	454.8

Script times reduce by around 2 seconds when moving from 1333mhz memory to the ADATA running at around 1600mhz. When we move to 1900mhz, the time reduces further by just over 2 seconds.
